Rated Power Voltage:
3-phase 1140V, 2300V, 50-60Hz±5%, Voltage Imbalance Rate <3%
Rated Voltage:
Maximum Output Voltage Is The Same As The Input Power Supply Voltage
Rated Current:
Continuous Operation At 100% Rated Current
Overload Capacity:
150% Rated Current For 1 Minute, 180% Rated Current For 2 Seconds
Output Frequency:
0Hz ～ 600Hz ，can Set
Control Method:
VVVF Control With Optimized PWM And Standard PWM Options, Vector Control, V/F Control
Frequency Resolution:
Digital Setting: 0.01Hz
Starting Frequency:
0Hz ～ 10Hz
Torque Boost:
Torque Boost 0.0% ～ 20.0%
V/F Waveform:
Five Modes: Constant Torque V/F Curve, One Mode Of User-defined Multi-segment V/F Curve, And Three Modes Of Torque Reduction Characteristic Curves (2.0 Power, 1.7 Power, And 1.3 Power)
Acceleration And Deceleration Curve:
Two Modes: Linear Acceleration/deceleration And S-curve Acceleration/deceleration; Two Types Of Acceleration/deceleration Time, With A Maximum Time Of 3000 Seconds
DC Braking:
DC Brake Start Frequency: 0-15.00Hz Brake Time: 0-60.0 Seconds Brake Current: 0-150%
Multi-speed Operation:
Implement Multi-segment Speed Operation Through Built-in PLC Or Control Terminals
Automatic Voltage Regulation (AVR):
Maintain A Constant Output Voltage When The Grid Voltage Changes By 10%
Automatic Energy-saving Operation:
Automatically Optimize The V/F (Voltage/Frequency) Curve Based On The Load Condition
Communication Function:
Equipped With An RS485 Standard Communication Interface, Supporting MODBUS
Operation Order Channel:
LED Keyboard, Control Terminals, Serial Port (RS485)
Frequency Setting Channel:
LED Keyboard, Simulated Potentiometer, LED Keyboard With ▲ And ▼ Keys,NO.assignment For Function Codes, Serial Port, UP/DOWN Terminals, Analog Voltage/current, Combined Setting
Digital Input Channel:
2 Channels For Start-stop Control Terminals, 6 Channels For Programmable Digital Inputs
Analog Input Channel:
2 Channels Of Analog Signal Input: 2 Channels Switchable Between 0-10V And 0/4-20mA
Digital Output Channel:
2 Channels Of Open-collector Output, 2 Channels Of Relay Output
Analog Output Channel:
2 Channels Analog Signal Output: 2 Channels Switchable Between 0-10V And 0/4-20mA
LED Display:
Can Display Or Set Inverter Parameter
Protect Function:
It Offers Multiple Protection Functions, Including Short Circuit, Overcurrent, Overload, Underload, Overvoltage, Undervoltage, Phase Loss, Overheating, External Fault, PID Feedback Disconnection, And 485 Disconnection Protection Functions
Optional Accessories:
Optional Accessories Touch Screen, Control Room
Application:
Indoor, Shielded From Direct Sunlight, Free From Dust, Corrosive Gases, Oil Mist, Water Vapor, Etc.
Altitude:
Below 1000 Meters (operation At Altitudes Above 1000 Meters May Requirederating)
Environment Tempreture:
- 10℃~+ 40℃
Humidity:
Less Than 90% Relative Humidity, No Condensation
Vibration:
Less Than 5.9m/sec2（0.6G）
Storage Tempreture:
- 20℃~+ 60℃
Cooling Method:
Forced Air Cooling
Installation Method:
Wall-mounted Or Floor-standing
